OpenId Connect

Authenticate users through an identity provider based on OpenId.

Plugin Configuration

To enable this plugin, you need to:

  1. Go to the Integrations / Plugins page.

  2. Select the Security category.

  3. Locate the OpenId Connect card.

  4. Click on the card switch to activate the plugin.

  5. Configure the plugin properties and save.

Here is the list of all the properties that can be used in the plugin configuration.

PROPERTIES

Identity Provider Name

The name of the identity provider supporting the OpenId Connect protocol.
Type: STRING | Mandatory

Grant Type

Define the way the client interacts with the OpenId server.
Type: SELECTION | Mandatory | Default: AUTHORIZATION_CODE

Authorization URL

The endpoint of the authorization server, used to get the authorization code.
Type: STRING | Mandatory

Access Token URL

The endpoint of the authentication server used to exchange the authorization code for an access token, and if needed refresh it.
Type: STRING | Mandatory

Client ID

The client identifier provided during the registration process in the target identity provier.
Type: STRING | Mandatory

Client Secret

The client secret provided during the registration process in the target identity provier.
Type: PASSWORD | Mandatory

Scope

The scope of the access request. It can be list of space-delimited values (e.g. openid email profile).
Type: STRING | Optional

Client Authentication

The method that client uses to authenticate to the Authorization Server when calling the Token Endpoint
Type: SELECTION | Mandatory | Default: CLIENT_SECRET_POST

Logout URL

The URL to automatically navigate when the user logs out of the application, in order to trigger the logout also from the remote identity provider system.
Type: STRING | Optional

User Info URL

The endpoint URL called to obtain the details of the authenticated user.
Type: STRING | Optional

User Property Mapping

The mapping between the user details field names and the Servitly user properties. The mapped properties will be automatically updated on each user login.
Type: KEY_VALUE | Optional

Create Missing Users

The flag that indicates whether, during the first login, missing users should be created based on the presence of the user property mapping 'customerCode' or 'partnerCode'.
Type: CHECKBOX | Optional

Login Button Label

The label to display in the application login page (e.g. Login with Google).
Type: STRING | Optional

Login Button CSS Class

The space-delimited list of classes aplied on the login button (e.g. bg-blue text-bold).
Type: STRING | Optional

Google Open Id Connect configuration

Grant Type

Authorization Code

Auth URL

https://accounts.google.com/o/oauth2/v2/auth

Access Token URL

https://oauth2.googleapis.com/token

Client Id and Secret

https://console.cloud.google.com/apis/credentials

Scope

openid email profile

User Info URL

https://oauth2.googleapis.com/tokeninfo

Login Button Label

Login with Google

Login Button CSS Class

bg-blue mt-4

For more details about how to configure the Google OpenID authentication refer to this guide.

The open-id requires a redirect URL to return to once the user has logged in to the external authentication system.

https://<TENANT_NAME>.<DOMAIN_NAME>/open-id

In the case you are using the default Servitly Mobile App, it is needed to register also a redirect URL having the additional appScheme parameter.

<BASE_REDIRECT_URL>?appScheme=servitly

This is needed by a Google security policy which does not allow invoking auth URLs directly from a mobile app. In order to use OpenId login from a Mobile App, the authentication flow pass through the system browser, and finally, the user is redirected to the installed mobile app responding to a certain scheme. The scheme generally corresponds to the name of the tenant, but for the default Servitly App is just servitly.

Login Experience

With the plugin enabled and configured, the login page is enriched with a new login button (eg. Login with Google).

When the user, who needs to log in, presses the button it is redirected to the OpenId authentication flow page, and when authenticated is redirected back to the application.

Once the callback URL is called during the authentication flow, the system searches for a user having the same email, and if found, the user is automatically authorized to access it.

Note that, when using the Servitly mobile application, for security reasons, the authentication flow passes through the operating system browser.

Automatic Login

In case you are integrating the DPS in a legacy app with its own SSO, when a user needs to enter the DPS application without performing an explicit login, you can redirect it to a special URL which triggers the authentication flow.

https://acme.servitly-sandbox.com/open-id-start-flow

By navigating this URL, the user experience is the same as the user clicks on the Login with.... button. In case the user is already logged in on the external identity provider, the user is automatically authenticated and redirected to the DPS application home page.
